LFT SERIES
Direct Rovings for LFT are coated with a silane-based sizing and compatible with PP, PA ,
TPU and PET resins.
LFT SERIES
Direct Rovings for LFT used in automobile, electronic and electrical, communication, sports equipment, medical equipment and other fields.
PRODUCT FEATURES
1.Good integrity
2.Excellent abrasion-resistant and less fuzz.
3.Good compatibility with PP resin.
4.Excellent processing and mechanical properties.
5.Good dispersion,suitable for low tension system
6.High mechanical properties,suitable for high tension system.
7.Super white color
End-Use Markets
STANDARD PRODUCTS
Product ID | Nominal Tex g/km | Nominal Filament Diameter μm（microns） |
LFT166-400 | 400 | 14 |
LFT166-600 | 600 | 14 |
LFT166-1100 | 1100 | 14 |
LFT166-1200 | 1200 | 16 |
LFT166-2400 | 2400 | 17 |
PRODUCT DATA
Type of Glass | ECR-glass formulation |
Resin Compatibility | PP |
Binder Type | Silane |
Linear Density (Tex or Yield) | Nominal ± 5% |
Size Content (LOI % weight) | 0.40 ± 0.15 |
Moisture (%) | ≤ 0. 10% |
Breaking Strength(N/Tex) | ≥0.30 |
Packaging | Plastic film wrapped cylindrical packs with top central opening. |
Pallet Size | 1120mm*1120mm |
Package Size | Cylindrical 10.5” – 12.0” DIA (26 cm-30 cm) X 10.25" (26cm) HEIGHT |
Package(doff)Weight | 40 lb. Each (nom) or 18 kg. (nom) |
Pallet Configuration | 4 Layers or 3 Layers of 16Packages,Stretch Wrapped and Top Protected |
Storage Recommendations | Stack pallets to a maximum two high. |
